Blackout System Greenhouse Support by Oone
1.Introduction of Product
• Hot dip galvanized frame
This kind of special treated steel has good anti-corrosion and anti-rust effects, which extend the service life of the greenhouse. Special designed structure and accessories make sure the outstanding performance of the greenhouse.
• High quality covering material
With more than 80% light transmission and low cost,the PE is one of the best material to be widely used in the greenhouse.
2.Product Parameters
| Specification of greenhouse | |
| Production name | Single span plastic tunnel greenhouse |
| Length | 60-200m,customize |
| Width | 6m,7m,8m,9m,10m,can customized |
| Roof height | 3-6m,can customized |
| Greenhouse farme | Hot galvanized steel pipe,diameter is 25mm,32mm,40mm,42mm,50mm,60mm |
| Cover film | PE/PO 0.12/0.15/0.2mm,customize |
| Ventilation | Two sides ventilation by manual/electric roll up machine |
| Wind load | 80-130km/h |
| Snow load | 0.5KN/M2 |
| Plants hanging load: | 0.15KN/m2 |
| Rain drainage | 140mm3/h |
| Option | Cooling fan,cooling pad,shade net,heater,lights,irrigation system |
Greenhouse Shading System:
A. Outside Shading system
The main function of the system is shading and cooling in summer and making sunshine diffuse in greenhouse and preventing crops from strong light burning. Because of blocking a lot of light to enter, it reduces internal heat accumulation of greeenhouse effectively. Generally, it can reduce greenhouse temperature by 4-6ºC Ultroviolet resistant, anti hail and reduce harm from the top curtain of different sunshade rates is selected for different crops which needs a variety of sunlight shading:summer by closing the curtain can effectively refelect off part of the sun,which can reduce the greenhouse teperature by four to six degrees Celsius.
B. Inside Shading System
Fog prevention and drip prevention:when internal sunshade system is closed,two independent spaces are formed that prevent fog and dip formation inside.
Energy saving and eco frendily:effective inner heat can be overspill through heat transmission or exchange, and therefore to reduce energy cost
Watering saving:Glass greenhouse can effectviely reduce crops and soil evapporation that can keep the air humidity. And therefore, water for irrigation is saved.
(2).Greenhouse Cooling system
Use evaporation cooling principle of water to realize cooling. There is a specially-made hydrophobic wet pad wall. When the air penetrates wet curtain medium, it conducts heat exchange with vapor on moist medium surface so as to realize humidification and cooling for the air.
A.Wet Pad
It consists wet pad, aluminum alloy frame and wet pad water system.
B. Fan
Size:1380*1380 or 1250*1250
(3).Irrigation and fertilization system;
A. Irrigation and fertilization water treatment system with reasonalbe design improves absorption function of crops toward fertilizer.Meanwhile, it improves crop quality
B. It is especially suitable for area with poor water quality and crop greenhouse which has high requirements for planting water quality
C. The advcanced treatment process is combined with greenhouse production process effectively.
(4).Greenhouse Ventilation System:
Greenhouse ventilation system can be divided into two kinds of ventilation systems. One is continuous ventilation system and the other isinterlacing ventilation system. Both of these two kinds of ventilation systems are now widely used in agricultural planting, sightseeing and entertainment and other fields.
(5).Automatic control system and so on.
· How many days to ship?
Usually takes 1-3days. If have the large quantity, We will offer you a quote with the lead time.
· What are the shipment options?
We can send you our items by Ship, Post or Express(such as FedEx, DHL, UPS, TNT SF) on time.
· Can I get your sample before make order?
Sure! Free small samples are available. You only need to give us your receiver name and address,
telephone number. It is better to have account number of the express company, such as DHL, TNT,
UPS, Fedex etc.
· What's the Design format requirement?
All images used during artwork preparation should be 150dpi with CMYK at the Finished full Size
to ensure good quality print.
The format such as AI, PDF, PSD, TIFF, JPG, png,will be great
· How can I get accurate color
Because computer monitors have aberration,accurate color requirments for pring customers please
provide PANTONE(pantone) color value or color samples.
· I'm not sure if my artwork is correct, what should I do?
If you have any question, please feel free to ask us. we will give honest and accurate advice to you.
We are the experts for printing.
· Where would i need to send the larger images file?
You can send artwork to us with WeTransfer, Dropbox.
Company Advantages
· Due to our special technics and high quality material, blackout system greenhouse is much prior than that from mainland.
· Its performance is tested by potential customers and the market research groups.
· Jiangsu Oone International Trading Co., Ltd.'s development has satisfied the blackout system greenhouse industrial production requirements.
Company Features
· Jiangsu Oone International Trading Co., Ltd. has been performing well in developing and manufacturing blackout system greenhouse. We are reputable in China after serving the market for years.
· Jiangsu Oone International Trading Co., Ltd. has a professional design team to design the most unique blackout system greenhouse.
· Adhere to the spirit of customer first, Oone will be encouraged to ensure service quality. Call!
Application of the Product
blackout system greenhouse can be applied to different industries, fields and scenarios.
We strive to provide customers with efficient, complete, and flexible solutions based on their needs.
